Smart Client Player

A project in XProtect Smart Client – Player is a collection of files that are created when video is exported in database format from XProtect Smart Client. Your user settings, including information about your views, are stored as part of a project. The Project pane appears when you click Setup. In setup mode, you can: Change the name of the.

VLC Media Player which is not mandatory but can handle all the streams and files coming from Netcam Studio; Information. Netcam Studio is compatible with: Windows 7, 8 and 10; Windows Server 2008, 2012, 2016 and 2019; The installation package contains: Netcam Studio Server (Netcam Studio X) Netcam Studio Service; Netcam Studio Windows Client. VLC media player, a free, open-source and cross-platform media player that has a built-in UPnP-client that lets the user access the contents listed from an UPnP Media server. Though a very complete media player in itself, it does not provide any UPnP Control Point capabilities, nor can the player be controlled as a UPnP compliant Media Renderer.

Managing views in XProtect Smart Client – Player

You create and manage views by clicking Setup on the XProtect Smart Client – Player toolbar. The panes on the left-hand side turn yellow.

Project pane (explained)

The Project pane appears when you click Setup. In setup mode, you can:

Change the name of the project.
Create or open a project
Assign passwords to projects - only people with permission can view a video. You can also assign passwords to devices when you export them. To avoid having to keep track of several database passwords, you can assign a single password to the overall project. If you do not assign an overall password and you have databases with passwords added to your project, you will be asked to enter a password for each database when you open the project. If you assign a password to a project, you cannot delete it. However, you can change the password or create a new identical project in the Project pane.

Views pane (explained)

In the Views pane in XProtect Smart Client – Player, you can add, edit, and delete views. You can also search for views and cameras.

Overview pane (explained)

The Overview pane in XProtect Smart Client – Player displays the cameras, microphones, speakers, webpages, images, and plug-ins assigned to the project. When you have selected a device, you can delete it and rename it. You can link speakers and microphones to cameras. Then associated audio is automatically selected when you view recorded video for a particular camera.

To open a database from an archive or previously exported material, click the button. The Open Database wizard appears.

When you delete a device, this does not delete the actual database files associated with the device, it just removes them from the project.

Digital signatures (explained)

This feature is only available in certain XProtect VMS systems. For information about the features in your system, see Surveillance system differences.

You can use digital signatures to verify the authenticity of your recorded video. This is useful, for example if you want to demonstrate that the video has not been tampered with.

There are two stages of verification. You can verify:

whether the video has been modified after it was recorded. The recording server creates a digital signature for the recording. Later when you view exported video in Smart Client – Player, you can compare the recording signature with the one that was originally created by the recording server.
whether video that you export in XProtect Smart Client has been modified after it was exported. During the export process, XProtect Smart Client creates a signature for the export file. Later when you review the exported evidence in Smart Client – Player, you can compare the export signature with the one that was created during the export.

If you find that there is a discrepancy, there is reason to question the reliability of the video evidence.

The original digital signatures are contained in the PublicKey.xml and Public Key Certificate.xml files in these locations:

XProtect Smart Client - <export destination folder><export name>Client FilesDataMediadata<camera name><camera name>Export signatures
Management Client - C:Program FilesMilestoneManagement ServerToolsCertificateIssuer

There are two scenarios where digital signatures are excluded during the export process:

If there are areas with privacy masksA blurred or solid color that covers an area of the video in the camera view. The defined areas are blurred or covered in live, playback, hotspot, carousel, smart map, smart search, and export modes in the clients., digital signatures for the recording server will be removed in the export.
If the data you are exporting is very close to the current date and time, the digital signature for the recording server might not be included for the whole sequence. In this case, only part of the export will have digital signatures added.

The export process will complete, but when you verify the signatures, you will see that the digital signatures for the recording server were removed or partially OK.

If you are looking for Milestone XProtect Smart Client, you have come to the right place. We explain what Milestone XProtect Smart Client is and point you to the official download.

What is Milestone XProtect Smart Client?

The Milestone XProtect Smart Client software from Milestone is a client program for those using video surveillance systems. It serves as a management environment for those running these sorts of installations, providing users with a variety of tools for surveillance system administration. The Smart Client software may actually be paired with the Milestone Mobile software if the user also wants a way to access surveillance data from portable devices and not just his desktop. Like Smart Client, the mobile version is free to use.
Smart Client provides users with overlay map visuals for quick system overviews. The maps are interactive, promoting user efficiency, and even in camera view, users can manipulate and manage cameras directly. Virtual joystick control is supported, and multi-screen function is as well. It supports intelligent searching, integrated video timelines, and video scene storyboarding. Users can also bookmarks videos or scenes they think to be of interest.
As with many other programs of this type, Smart Client has a tool for alarm management. It also lets users work with each feed separately, e.g. they can view recorded video from one camera while viewing the real-time feeds from others.

Xprotect Smart Client Download

Download Milestone XProtect Smart Client from the developer

File.org does not provide software hosting. We send you directly to the developer's site, to make sure you download the latest, original version of the program.

File types supported by Milestone XProtect Smart Client

Our users primarily use Milestone XProtect Smart Client to open these file types:

About file types supported by Milestone XProtect Smart Client
